ISF2.8

ISF2.8 Series Specification:

Type:  4 cylinders in-line

Displacement（L): 2.78

Max Power(HP): 161

Peak Torque(Nm):360

Weight(Kg):214

Application: Pick-up truck

Model list for ISF2.8

Model          Rated Power（HP/RPM）   Peak Torque（N.m）  Emission

ISF2.8s3129T         129 (96) @ 3200     310 @ 1600-2700        Euro III

ISF28s3148T          148 (110) @ 3200    360 @ 1800-2700          Euro III

ISF2.8s4107P          107 (80) @ 3600     280 @ 1400-2400        Euro IV

ISF2.8s4129P          129 (96) @ 3600    280 @ 1400-3000        Euro IV

280 @ 1250-3000        Euro IV

ISF2.8s4161P          161 (120) @ 3600   360 @ 1500-3000        Euro IV

ISF2.8s4129T          129 (96) @ 3200   310 @ 1600-2700        Euro IV

ISF2.8s4129V          129 (96) @ 3200   310 @ 1400-2700      Euro IV

ISF2.8s4148T          148 (110) @ 3200    360 @ 1800-2700        Euro IV

ISF2.8s4148V        148 (110) @ 3200   360 @ 1500-2700      Euro IV

ISF2.8s4117V        117 (87) @ 3200   260 @ 1300-3200        Euro IV

ISF2.8s5161P          161 (120) @ 3200   360 @ 1600-3200        Euro V

lSF2.8s5129P          129 (96) @ 3600   280 @ 1200-3000        Euro V

ISF2.8s5148T        148 (110) @ 2900     360 @ l500-2900        Euro V

ISF2.8s5129T          129 (96) @ 2900   315 @ 1500-2900        Euro V

F series Foton Cummins ISF series 2.8L and 3.8L light-duty engines are two in-line four cylinder high-pressure direct injection diesel engines newly developed by Cummins with huge investment. They are a new generation of fully electronic controlled light-duty diesel engines for the future, with a power range of 107-168 HP. These two engines have the characteristics of strong power, reliability and durability, compact structure, high efficiency and economy, and can meet the emissions of Euro IV (National IV), Euro V (National V) and euro VI, and can be easily upgraded.
